Address Cleanse API

• The Address Cleanse API is a web service that can be used to perform address validation, deduplication and adding extra data. Make changes to imported data files.
• It follows RESTful principles – accepting HTTPS requests and returning JSON response documents.
• See the Address Cleanse API reference for the full interface definition.

Authentication

Authorization: Bearer $TOKEN_VALUE

Job Configuration

There are 3 different methods to be used in uploading a file. This is to allow for the uploading of large files and in avoiding import latency.

Begin

First call the begin method, giving it a size and filePrefix (name).

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/files/upload/begin?size=XXX&filePrefix=NAME

Parameters:

Response:

{
  "fileId":"CustomerAddresses1234.dat",
  "chunkUrl":"https://filesvr.hopewiser.com.au/filesvr/upload/chunk"
}

Chunk

Then call the chunk method using the chunkUrl (in place of the service endpoint used in all other methods here), the fileId returned by /begin and an idx indicating which chunk this is, starting from zero. The file data should be sent in the body of the HTTPS POST request as raw binary data bytes.

PUT https://filesvr.hopewiser.com.au/filesvr/upload/chunk?fileId=XXX&idx=0

PUT https://filesvr.hopewiser.com.au/filesvr/upload/chunk?fileId=XXX&idx=1

etc.

Parameters:

It is recommended the chunks be no larger than 10 MB; especially if your application is browser based. Call this method repeatedly for each part of the file you upload, incrementing the idx parameter by 1 each time.

End

Once the file data is completely uploaded, call the end method with the fileId returned by /begin, and optionally a hash field containing the sha256 hash of the file. If a hash is provided it will be compared with the file data stored on the server to guarantee the uploaded file’s integrity.

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/files/upload/end?fileId=XXX&hash=YYY

Parameters:

A list of uploaded files and their metadata can be retrieved using the files method which takes no parameters and returns a JSON array containing a description of each uploaded file. This request returns files that have been processed/run. Those that have only been uploaded, via the proceeding instructions, will not be shown.

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/files

Response:

[
  {
    "id": 147,
    "name": "input_address.txt",
    "inputFileServerId": "bureauInput7122032991119785308.dat",
    "cols": 6,
    "rowCount": 597,
    "delimiter": ",",
    "hasHeader": true,
    "useQuotes": false,
    "creationDate": 1510939445,
    "lastUpdate": 1510939445
  }
]

The dates in the response are given using Unix time, which is the number of seconds that have elapsed since January 1, 1970 (midnight UTC/GMT), not counting leap seconds (in ISO 8601: 1970-01-01T00:00:00Z).

Start a cleanse job

To start a processing run on an uploaded file, call the run method, providing the inputFileId which was returned in the /upload methods, and a name to identify this job. The request body should contain the JSON settings data previously generated from the web interface and exported using Export settings for API in an earlier step.

PUT https://www.hopewiser.com.au/online-address-cleanse/api/v1/run?inputFileId=CustomerAddresses1234&name=CleanseRun1

Parameters:

Body:

{
  "protocol": 2,
  "mafId": 2,
  "inputFileDesc": {
    "cols": 7,
    "delimiter": "|",
    "hasHeader": true,
    "useQuotes": true
  },
  "inputFields": [
  {
    "name": "Add Line 1",
    "mappingId": 6,
    "mappingOrder": 9,
    "inputOrder":14069
  },
  {
    "name": "Add Line 2",
    "mappingId": 6,
    "mappingOrder": 10,
    "inputOrder":14070
  },
  {
    "name": "Add Line 3",
    "mappingId": 6,
    "mappingOrder": 11,
    "inputOrder":14071
  },
  {
    "name": "Add Line 4",
    "mappingId": 6,
    "mappingOrder": 12,
    "inputOrder":14072
  },
  {
    "name": "Add Line 5",
    "mappingId": 6,
    "mappingOrder": 13,
    "inputOrder":14073
  },
  {
    "name": "City",
    "mappingId": 6,
    "mappingOrder": 14,
    "inputOrder":14074
  },
  {
    "name": "Country",
    "mappingId": 0,
    "mappingOrder": 15,
    "inputOrder":14074
  }
  }],
  "outputFields": [{
    "groupId": 1
  },
  {
    "groupId": 8
  },
  {
    "groupId": 2
  },
  {
    "groupId": 3
  },
  {
    "groupId": 11
  },
  {
    "groupId": 12
  },
  {
    "groupId": 13
  },
  {
    "groupId": 14
  }],
  "dedupe": {
    "duplicationLevel": 2,
    "dedupeSeparateFile": false
  },
}

Response:

{
  "runId": 49
}

Get the status of a job

Depending on the size of the file and the options selected, the processing run could take only a few seconds or several minutes. To determine the current status of the job you can poll using the status method, giving it the runId returned from /run. This will return a block of JSON text containing the current status of the job. The returned HTTP status code will also change. While the job is running the returned HTTP status will be 404, once the job is complete it will become 200.

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/run/status?runId=49

Parameter:

{
    "name": "CleanseRun1",
    "statusCode": 6,
    "statusDesc": "Processing",
    "stage": {
        "stageCount": 7,
        "currentStage": 5,
        "stageName": "Post processing",
        "stageStatus": "Postprocess",
        "stageProgress": 0.14285714285714286
    }
}

The stage part of the response will only appear whilst the processing run is in progress. Once the cleanse part of the job is complete the response will only contain the name, statusCode and statusDesc sections.

Possible status codes

The number and values of the stages in the stage object are subject to change. The field names are fixed, but their values may be updated.

For example, there are currently 11 stages, but that number may increase or decrease in future. If it does change the stageCount will update to reflect this.

Once a job is complete various statistics and metadata is available to download. These can be viewed without payment. To download the results file however, it must first be paid for.

All the results methods take as a parameter the runId returned by the run method to identify which job is the one of interest.

Statistics

To obtain details of matches for the various categories of checks made by Address Cleanse (address matches, de-duplications and suppressions), use the statistics method…

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/results/statistics?runId=49

Parameter:

Body:

{
  "recordCount": integer,
  "codingStats": [
    {
      "name": string,
      "description": string,
      "count": integer
    }
  ],
  "addressUpdateStats": [
    {
      "name": string,
      "description": string,
      "count": integer
    }
  ],
  "dedupeStats": [
    {
      "name": string,
      "description": string,
      "count": integer
    }
  ],
}

Response:

{
    "recordCount": 76,
    "codingStats": [
        {
            "name": "Matched",
            "description": "A correct address",
            "count": 11
        },
        {
            "name": "UnmatchedPremise",
            "description": "The premise, e.g. house number, was not found",
            "count": 1
        },
        {
            "name": "UnmatchedStreet",
            "description": "The thoroughfare, e.g. street, was not found",
            "count": 1
        },
        {
            "name": "UnmatchedTown",
            "description": "The town was not found",
            "count": 62
        },
        {
            "name": "Unmatched",
            "description": "No parts of the address could be verified",
            "count": 1
        }
    ],
    "dedupeStats": [
        {
            "name": "Unique",
            "description": "The record is unique",
            "count": 98
        },
        {
            "name": "Parent",
            "description": "The first record that is a duplicate based on the level selected",
            "count": 1
        },
        {
            "name": "Child",
            "description": "The record is a duplicate of a parent record",
            "count": 1
        }
    ],
}

The name and description for the codingStats may be one of the following;

The name and description for the addressUpdateStats may be one of the following;

The name and description for the dedupeStats may be one of the following;

Costs

To see a breakdown of the various charges incurred for the run, use the costs method…

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/results/costs?runId=49

Parameter:

Body:

[
  {
    "name": string,
    "cost": integer
  }
]

Response:

[
    {
        "name": "Address Validation",
        "netcost": 3072,
        "cost": 3610
    },
    {
        "name": "De-duplication",
        "netcost": 43,
        "cost": 50
    },
]

The name may be one of the following;

• Processing Charge
• Address Validation
• De-duplication

The cost is in Australian Dollars, excluding GST.

Download results file

To retrieve the results (upon completion of payment step), call the file method. This will return a URL from which a zip file containing results and statistics can be downloaded. Please note the “Authorization: Bearer” token is required to authenticate the download URL.

GET https://www.hopewiser.com.au/online-address-cleanse/api/v1/results/file?runId=49

Parameter:

Response:

{
  "downloadUrl": "https://filesvr.hopewiser.com.au/filesvr/download?downloadName=AddressCleanseResults.zip&fileId=CleanseRun1234.dat"
  "fileServerId": "job-13952588965434633508814.dat",
}
